Acer Aspire V5-431 - Reinstalling the Thermal Module

3-58 Machine Maintenance
Reinstalling the Thermal Module 0
1. Place the thermal module into the mainboard.
Figure 3-81. Thermal Module
2. Tighten the spring-loaded captive screws securing the thermal module. Follow the screw
sequence indicated on Figure 3-82.
Figure 3-82. Thermal Module Screws
Table 3-82. Screws
Step Screw Quantity Screw Type
Thermal Module Reassembly – 5 –
