3-68 Machine Maintenance
Reinstalling the Touchpad Board 0
1. Place the touchpad board into the upper case assembly.
Figure 3-97. Touchpad Board
2. Connect the touchpad cable to the touchpad board (1), then press the connector latch (2)
until it locks into place.
Figure 3-98. Touchpad Cable
3. Place the touchpad cable into the touchpad board (1), then secure the touchpad cable to
the board using adhesive tape (2).
To Next Page
