FRU (Field Replaceable Unit) List 6-5
7 LVDS combo cable 50.4TU08.001
8 Antenna WIFI main (left) 25.90ADQ.001
9 Antenna WIFI aux. (right) 25.90ADR.001
10 Keyboard 60.4TU09.002
11 Power board
12 Power board EMI shield / mylar 40.4TU18.001
13 Touch pad bracket assembly 60.4TU07.002
14 Touch pad module 60.4TU15.002
15 Upper case assembly 65.4TU12.001
16 DC-In cable 50.4TU04.001
17 Wireless LAN card
18 Mainboard
19 Battery
20 ODD bracket 33.4TU05.001
21 ODD module
22 ODD bezel assembly 60.4TU10.001
23 UMA battery cable 50.4TU14.001
24 HDD cable 65.4TU14.001
25 HDD module
26 Lower case assembly 60.4TU27.001
27 Dummy card 42.4TU15.001
28 DIMM cover 60.4TU11.001
Table 6-1. Main Assembly Exploded Diagram
No. Description Part Number
