36
English
5 Adjust the angle and positioning as necessary.
Note: The appropriate type of screw and washer for each model is
listed in the table below. 3 mm diameter screws are enclosed in
the screw pack.
Models Screw Type B Washer Type
Diameter (mm) Length (mm) Large Small
H7532BD/E152D/
HE-812
325VV
Tightening Screw
Allen Key
Tightening Screw
Allen Key
SCREW SPEC. M3 x 25 mm
150.00 mm
87.35 mm
