Projector Overview
Projector Outlook
Front/upper side
Rear side
# Description # Description
1 Speaker grills 4 Indicator LED
2 Remote control receiver 5 Control panel
3 Projection lens
# Description # Description
1 LAN (RJ45 port for 10/100M
Ethernet)
8 RS232 connector
2 USB connector (Type A) 9 Audio output connector
3 USB-C connector 10 USB-A (for wireless dongle)
4 HDMI connector 11 Kensington™ lock port
5 USB connector (Type A) 12 Security slot
6 12V DC output connector 13 Power socket
7 S/PDIF port 14 Tilt adjusting wheel
1
2
1
3
4
5
1414 1414
11
12
13
1 4 53 9 1086 72
