51
12.3 Connect the HDD SATA cable and HDD SATA power cable with MB
13. Cable routing position
14. Fix two screws of left side cover
Step
Screw
Quantity
Screw Type
Part Number
Torque/ kgfcm
Side cover
#6-32*5
mm
ij
pcs
N/A
6.0~7.0Kgf/cm
