Acer Predator PO3-600 E - FRU (Field Replaceable Unit) List; Exploded Diagram

93
FRU (Field Replaceable Unit) List
Exploded Diagram
Item
Description
Item
Description
1
Front Bezel
26
Screw #
6-32*5mm
2
LED Lens Left
27
Top Cover
3
LED Lens Right
28
MB Bracket down
4
PREDATOR Logo Left
2
9
HDD
Bracket
5
PREDATOR Logo Right
30
LED Holder Left
6
Front Bezel Rubber
31
G6
VGA Bracket
7
Front Bezel hook
32
VGA
Rubber
8
Screw F
3*8
33
VGA
Holder
9
Rubber Foot
15.8*2mm
34
PCI
Cover
10
Left ear
35
Rear Chassis
11
Screw
M3
36
Side Cover L
12
Right ear
37
FIO
Bracket
13
Power Button Deco
38
D
eco Right up
14
Power Button
39
D
eco Right down
15
Screw
40
D
eco Left up
16
Power switch Holder
41
D
eco Left down
17
Power switch cable
43
HDD
Rubber
18
Screw
44
EMI
gasket 105*6*0.5mm
19
Fan Holder
45
Front Led cable
20
Front Chassis
46
Led Power cable
21
Chassis Base
47
Screw
#6-32*5mm
22
PSU Rubber
48
MB Rubber
11*11*13mm
23
MB Bracket up
49
MB Rubber
7*4.5*6mm
24
ODD Bracket down
50
Cable Clip
-1
25
ODD Bracket up
51
Cable Clip
-2
Chapter6
