Follow these instructions to install an add-on card:
1. Remove a blanking plate from the system case corresponding to the slot you are going to use.
2. Install the edge connector of the add-on card into the expansion slot. Ensure that the edge connector
is correctly seated in the slot.
3. Secure the metal bracket of the card to the system case with a screw.
* For reference only
For some add-on cards, for example graphics adapters and network adapters, you have to
install drivers and software before you can begin using the add-on card.
Follow these instructions to install the M.2 SSD card:
1. Demount the screw not used according to the length of your M.2 SSD card.
2. Insert the M.2 SSD card into NGFF slot in the fool-proof way.
3. Lock the screw as the following picture shows to make sure the M.2 SSD
card is installed in place.
For some add-on cards, for example graphics adapters and network adapters,
you have to install drivers and software before you can begin using the add-on card.
