26
fix Mainboard:
① MYLAR set position as shown in figure 1
② The main board the alignment as shown in figure 3.
③ The body aluminum film pumping away mylar
Connect the all cable and the paste all tapes as the below picture:
S4
S3
1
2
3
3
