MODE NO. 21 22
RESOLUTION
1920 x 1080 1920 x 1080
Dot clock(MHz)
148.5 138.5
f h
67.5 66.58
H-Total ( us ) 14.815 (2200 dots) 15.018 (2080 dots)
H-Sync ( us ) 0.296 (44 dots) 0.231 (32 dots)
H-B-P ( us ) 0.997 (148 dots) 0.578 (80 dots)
H-Active ( us ) 12.929 (1920 dots) 13.863 (1920 dots)
H-F-P ( us ) 0.593 (88 dots) 0.347 (48 dots)
f v
60Hz 60Hz
V-Total (ms ) 16.667 (1125 lines) 16.685 (1111 lines)
V-Sync ( ms ) 0.074 ( 5 lines) 0.075 ( 5 lines)
V-B-P (ms ) 0.533 ( 36 lines) 0.360 ( 24 lines)
V-Active (ms ) 16.000 (1080 lines) 16.219 (1080 lines)
V-F-P ( ms ) 0.059 (4 line ) 0.030 (2 line )
SYNC. H/V +/-
POLARITY
SEP . SYNC
Remark Detail timing
