Chapter 3
Machine disassembly
This chapter contains step-by-step procedures on how to disassemble the monitor for
maintenance and trouble shooting
NOTE: 1. The screws for the different components vary in size. During the disassembly process, group
the screws with the corresponding to avoid mismatch when putting back the components.
2. The monitor surface is susceptible to scratching! Therefore, lay the monitor on a soft surface
when mounting or removing the base.
3. Tools :Mylar,gloves,screw driver
Front View: (unit: mm)
To Next Page
