Acer T230H - Page 50

HDMI connector
The PIN assignment of the 14 pin HDMI connector / cable is as follows
Pinout of HDMI connector:
1
TMDS Data 2+
11
TMDS CLK shield
2
TMDS Data 2 shield
12
TMDS clk -
3
TMDS Data 2-
13
CEC
4
TMDS Data 1+
14
No connect
5
TMDS Data 1 Shield
15
SCL
6
TMDS Data1-
16
SDA
7
TMDS Data 0+
17
ground
8
TMDS Data 0 Shield
18
+5V power
9
TMDS data 0-
19
hot plug detect
10
TMDS clk+
20
Shell
