ITEM PART NUMBER PART DESCRIPTION UNIT ITEM PART NUMBER PART DESCRIPTION UNIT
1 34WCT9LB020 WCT9-M1 LCD BEZEL SUB ASSY(OTM) 1 17 DDW610CG009 WIRE ASSY(6/6P F/F 10CM P2.54/2.54)GLE 1
2 23W0T9BB004 W0T9-A1 BUTTON/B ASSY 1 18 DDWA407G008 WIRE ASSY(10P/10P; F/F 40CM P2/1.5)GLE 1
3 ATCWCT9M107 WCT9-M1 CAMERA MODULE WITH GLASS 1 19 DND4262S106 SPEAKER(4,2W,62.3*16*11)L22,R44 P2 GP 1
4 GBWCT901012 SPONGE 295*3.3*2(GBWCT901,R3A)B 2 20 36WCT9PS051 WCT9-M1 PCB SHIELDING ASSY(OTM) 1
5 GBWCT902019 SPONGE 518*3.3*2(GBWCT902,R3A)B 2 21 EAWCT909012 REAR COVER WCT9-M1(EAWCT909,R3A)OTM 1
6 DDW5451G009 WIRE ASSY(5/5P F/F 45CM P1/1)W/S 1 22 EBWCT911018 HINGE COVER-L WCT9-M1(EBWCT911,R3A)OTM 1
7 DDW6451G001 WIRE ASSY(6/5P F/F 45CM P1/1)W/S 1 23 EBWCT910011 HINGE COVER-R WCT9-M1(EBWCT910.R3A)OTM 1
8 JXWCT906015 TP ADHESIVE 288*5.5*0.15(JXWCT906,3A)OTM 2 24 KNWCT902011 STAND KIT ASSY WCT9-M1(KNWCT902,R3A)OTM 1
9 JXWCT905019 TP ADHESIVE 56*5.5*0.15(JXWCT905,3A)OTM 2 25 KNWCT903017 BASE KIT ASSY WCT9-M1(KNWCT903,R3A)OTM 1
10 FBWCT905018 BKT-R WCT9-M1(FBWCT905,R3A)OTM 1 A MBLI1004018 IO NUT LI1(MBLI1004,REV3A)GP 4
11 FBWCT906014 BKT-T WCT9-M1(FBWCT906,R3A)OTM 1 B MF30060PBJ5 SCREW F3.0*6.0-P(NI)GP 6
12 AA230HT0009 LCD 23"LTM230HT01(1920*1080,5MS)ACER CON 1 C MF40080BJ29 SCREW F4.0*8-B(BNI) GP 3
13 DEFC1639122 CABLE FFC(30P,163,,.W)WDZT PTI 1 D MF30060BJN0 SCREW K3.0*6.0 B(MC)WASH GP 1
14 AS56B4DCB04 PI 55W 4L(175*140,W/O SW)AIP-0191A 1 E MM30040IBJ9 SCREW M3.0*4.0-I(NI) GP 8
15 ATHWCT9M106 WCT9-M1 HUB MODULE(QCI CON) 1 F MM40100B244 SCREW M4.0*10-B BLACK (NYLOK)GP 4
16 21WC82RAF28 WCT9-M1 M/B ASSY(DUAL+A+HDMI RTD2482RD) 1
EXPLODED PART LIST
