Acer V176L Guide

Contents
Table of Contents
Important Safety Notice ................................................................................. 3
1. Exploded Diagram ...................................................................................... 4
2. Wiring connectivity diagram .................................................................... 5
3. Mechanical Instruction .............................................................................. 7
4. Disassembly and Assembly SOP ............................................................ 8
5. Troubleshooting ....................................................................................... 12
6. FRU List ..................................................................................................... 14
Safety Notice
Any person attempting to service this chassis must familiarize with the chassis and be aware
of the necessary safety precautions to be used when serving electronic equipment containing
high voltage

Acer V176L Specifications

General

3D	-
Panel type	TN+Film
Aspect ratio	5:4
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Display technology	LED
Viewing angle, vertical	160 °
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA)
On/off switch	Yes
Certification	TCO Certified Displays 6.0
Product color	Black
LED indicators	Power
Tilt angle range	-5 - 25 °
Panel mounting interface	100 x 100 mm
AC input voltage	120 - 230 V
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	15.5 W
Sustainability certificates	EPEAT Gold
Cables included	AC, VGA

Weight and Dimensions

Weight (with stand)	2600 g
Depth (without stand)	55 mm
Width (without stand)	369 mm
Height (without stand)	308.7 mm
Weight (without stand)	2200 g
