LCD Monitor General Specification
Driving system TFT Color LCD
Active Display Area 433.41(H) x 270.90(V)
Pixel pitch 0.258(H) x 0.258(W)
Contrast Ratio 1000 : 1
Response time 5ms
LCD Panel
Luminance of White
300(Typ.) cd/㎡
Separate Sync. H/V TTL
H-Frequency 30kHz – 83kHz
Input
V-Frequency 56-75Hz
Viewing angle
CR=10: H:170 / V:170 ( typ) ；CR=5: H:176 / V:176 ( typ)
Display Colors 16.7M
Display mode 1680 x 1050 @60Hz
ON Mode < 49W
EPA ENERGY STAR®
OFF Mode < 1W
Contrast control
Set to The value under user mode, which allows that the brightest two of 32 linear
distributed gray-scales (0～ 700mv) can be distinguished.
Power Source
90 V ~ 240 V，50 ± 3Hz, 60 ± 3Hz
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp: -30° to 65°C
Operating Humidity: 0% to 90%
Storage Humidity: 0% to 90%
Peak surge current < 100 A peak at 230 VAC and cold starting&25℃ & DC Output at Full-load
Power line surge
No advance effects (no loss of information or defect) with a maximum of 1 half-wave
missing per second
