Acer V277U User Manual

English
Installation
1. Turn off your computer and unplug your computer's power cord.
2. Connect the signal cable to the HDMI (optional) and /or DP (optional) input socket of the monitor, and the HDMI
(optional) and /or DP (optional) output socket of the graphics card on the computer. Then tighten the thumbscrews
on the signal cable connector.
3. Optional: Connect the audio input socket (AUDIO IN) of the LCD monitor and the line-out port on the computer with
the audio cable.
4. Insert the monitor power cable into the power port at the back of the monitor.
5. Connect the power adapter and power cord to the monitor, then to a properly grounded AC outlet.
Note: Audio output is only for audio output model. Please check user manual for more instruction.

Acer V277U Specifications

General

Color depth	8 bit
Pixel pitch	0.23 x 0.23 mm
Screen shape	Flat
Backlight type	LED
Display diagonal	27 \
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	75 Hz
sRGB coverage (typical)	100 %
Contrast ratio (dynamic)	100000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Display brightness (typical)	350 cd/m²
RMS rated power	4 W
Number of speakers	2
Product color	Black
Market positioning	Business
Tilt angle range	-5 - 25 °
Panel mounting interface	100 x 100 mm
AC input voltage	120 - 230 V
Energy efficiency scale	A to G
Power consumption (off)	0.4 W
Power consumption (standby)	0.46 W
Power consumption (typical)	32 W
Cables included	AC, DisplayPort

Weight and Dimensions

Depth (with stand)	208 mm
Width (with stand)	614 mm
Height (with stand)	464 mm
Weight (with stand)	6370 g
Depth (without stand)	66 mm
Height (without stand)	367 mm
Weight (without stand)	5390 g
