LCD Monitor General Specification
LCD Panel
Driving system TFT Color LCD
Active Display Area 337.92(H) × 270.336mm(V)
Pixel pitch 0.264mm(H) × 0.264mm(W)
Viewable angle (H) 90°+/-20° and (V) 90°+/-20°
Response time 5ms
Input
Separate Sync. H/V TTL
H-Frequency 30kHz – 80kHz
V-Frequency 55-75Hz
Display Colors 16.7M Colors
Max. Dot Clock 140MHz
Max. Resolution 1280 × 1024 @75Hz
EPA ENERGY STAR
®
ON Mode < 40W
OFF Mode < 1W
Input Connector D-Sub 15pin
Input Video Signal Analog:0.7 Vpp (standard),
Power Source 90~240VAC,47~63Hz
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp: -30° to 65°C
Operating Humidity: 0% to 90%
Storage Humidity: 0% to 90%
Dimension 376(W)×381(H)×162(D) mm
Leakage current < 3.5mA
Peak surge current < 55A peak at 240 VAC and cold starting
