Acer X233H

13
Factory Preset Timing of X233H
VESA MODES
Horizontal Vertical
Mode Resolution Total
Nominal
Frequency
+/- 0.5kHz
Sync
Polarity
Nominal
Freq.
+/- 1 Hz
Sync
Polarity
Nominal
Pixel
Clock
(MHz)
640x480@60Hz 800 x 525 31.469 N 59.940 N 25.175
VGA
640x480@72Hz 832 x 520 37.861 N 72.809 N 31.500
800x600@56Hz 1024 x 625 35.156 N/P 56.250 N/P 36.000
800x600@60Hz 1056 x 628 37.879 P 60.317 P 40.000
SVGA
800x600@72Hz 1040 x 666 48.077 P 72.188 P 50.000
1024x768@60Hz 1344x806 48.363 N 60.004 N 65.000
XGA
1024x768@70Hz 1328x806 56.476 N 70.069 N 75.000
1152x864@60Hz 1600 x 900 67.500 P 75.000 P 108.000
1280x960@60Hz 1800 x 1000 60.000 P 60.000 P 108.000
VESA
1280x720@60Hz 1650 x 750 44.955 P 59.940 P 74.176
SXGA 1280x1024@60Hz 1688 x 1066 63.981 P 60.020 P 108.000
1280x800@60Hz 1680 x 831 49.702 P 59.810 N 83.500
WXGA
1360x768@60Hz 1792 x 795 47.712 P 60.015 P 85.500
WXGA+ 1440x900@60Hz 1904 x 931 55.935 N 59.887 P 106.5
WSXGA+ 1680x1050@60Hz 2240 x1089 65.290 N 59.954 P 146.250
1600x1200@60Hz 2160 x 1250 75.000 P 60.000 P 162.000
1920x1080@60Hz 2576 x 1120 67.158 N 59.963 P 173.000
1920x1080@60Hz 2200 x 1125 67.500 N 60.000 N 148.500
UXGA
1920x1080@60Hz 2080 x 1111 66.587 P 69.934 N 138.500
IBM MODES
DOS 720x400@70Hz 900 x 449 31.469 N 70.087 P 28.322
MAC MODES
VGA 640x480@67Hz 864x525 35.000 N 66.667 N 30.240
ACER SPECIAL MODE
648x500@57.67 Hz 808 x 541 31.199 N 57.67 P 25.209
1024x600@60Hz 1312 x 622 37.320 N 60.000 N 48.964
