Acer X233H

15
Main Board Diagram
Flash Memory
SST25VF010A-33-4C-SAE
(U
4
0
2
)
Panel Interface
(
CN301
)
Crystal
12MHz
(X401)
Keypad Interface
(CN402)
Scalar IC NT68667UFG/C QFP-128L
(Include MCU, ADC, OSD)
(U401)
D-Sub
Connector
(CN101)
H sync
V sync
RGB
DVI
Connector
(
CN102
)
D-Data
D-Clock
