achilles A23S - BOOM SWING OPERATION; BOOM SWING

35
BOOM SWING OPERATION
1. Step on the left side of the pedal to swing
the boom to the left.
2. Step on the right side of the pedal to
swing the boom to the right.
3.
(1) Boom swing swtch (A) Swing to left
(B) Swing to right
BOOM SWING
WARNING
To avoid personal injury or death:
 Always keep your toes within
the edge of foot step; otherwise,
there is a possibility that your
toes will be caught between
swing frame and boom or
boom cylinder.
CAUTION
To avoid personal injury:
 When boom swing operation is
not in use, fold the boom swing
forward to fix the control from
unexpected move.
