DANGER
To avoid personal injury or death:
No directional changes should
be made when the excavator is
on the ramp. Should a change
of direction be necessary, drive
off the ramp completely and
make the turn.
When driving forwards or
backwards onto the truck, or
when swinging the upper body,
make sure that neither the
cabin or the gates of the truck
will be damaged.
When the excavator reaches
the point between the ramps
and the truck bed, halt and then
move very slowly until the
excavator reaches the
horizontal position.
Move the excavator onto the
truck only with the arm
completely pulled in.
Otherwise, the truck cabin
could be damaged when
swinging around the upper
body.
Do not jack up the machine
using its boom to load or unload
the excavator from the truck.
Dangerous situation could arise.
Transporting on a Truck
WARNING
To avoid personal injury or death:
After loading the machine on
the truck, lower the bucket and
dozer onto the truck bed. Lock
the swing frame with the swing
lock pin.
Prepare a platform to load or unload the
excavator. Take following steps when using
ramps.
1.
Apply the parking brakes of the truck,
and block the drive wheels from both
sides.
2.
Use mounting brackets to secure the
ramp properly. Connect the ramps
directly to the truck bed.
To Next Page
