DSIM-CC & DSIM-CF
Setup Guide Rev E
Channel
IRC
DIGITAL
Set 1
Set 2
Set 3
Set 4
MHz
MHz
Blue
Blue
Blue
Blue-Operation
Orange-Programming
74
523.25
525.00
7-Dits
4-Dits
1 IRC / 2 DIGITAL
Long dash
75
529.25
531.00
7-Dits
5-Dits
76
535.25
537.00
7-Dits
6-Dits
−
77
541.25
543.00
7-Dits
7-Dits
−
78
547.25
549.00
7-Dits
8-Dits
−
79
553.25
555.00
8-Dits
9-Dits
−
80
559.25
561.00
8-Dits
1-Dash
−
81
565.25
567.00
8-Dits
1-Dits
−
82
571.25
573.00
8-Dits
2-Dits
−
83
577.25
579.00
8-Dits
3-Dits
−
84
583.25
585.00
8-Dits
4-Dits
−
85
589.25
591.00
8-Dits
5-Dits
−
86
595.25
597.00
8-Dits
6-Dits
−
87
601.25
603.00
8-Dits
7-Dits
−
88
607.25
609.00
8-Dits
8-Dits
−
89
613.25
615.00
8-Dits
9-Dits
−
90
619.25
621.00
9-Dits
1-Dash
−
91
625.25
627.00
9-Dits
1-Dits
−
92
631.25
633.00
9-Dits
2-Dits
−
93
637.25
639.00
9-Dits
3-Dits
−
94
643.25
645.00
9-Dits
4-Dits
−
100
649.25
651.00
1-Dits
1-Dash
1-Dash
