9. LED Pilot Channel Blink Series Overview
Channel
IRC
DIGITAL
Set 1
Set 2
Set 3
Set 4
MHz
MHz
Blue
Blue
Blue
Blue-Operation
Orange-Programming
52
391.25
393.00
5-Dits
2-Dits
1 IRC / 2 DIGITAL
Long dash
53
397.25
399.00
5-Dits
3-Dits
54
403.25
405.00
5-Dits
4-Dits
55
409.25
411.00
5-Dits
5-Dits
−
56
415.25
417.00
5-Dits
6-Dits
−
57
421.25
423.00
5-Dits
7-Dits
−
58
427.25
429.00
5-Dits
8-Dits
−
59
433.25
435.00
5-Dits
9-Dits
−
60
439.25
441.00
6-Dits
1-Dash
−
61
445.25
447.00
6-Dits
1-Dits
−
62
451.25
453.00
6-Dits
2-Dits
−
63
457.25
459.00
6-Dits
3-Dits
−
64
463.25
465.00
6-Dits
4-Dits
−
65
469.25
471.00
6-Dits
5-Dits
−
66
475.25
477.00
6-Dits
6-Dits
−
67
481.25
483.00
6-Dits
7-Dits
−
68
487.25
489.00
6-Dits
8-Dits
−
69
493.25
495.00
6-Dits
9-Dits
−
70
499.25
501.00
7-Dits
1-Dash
−
71
505.25
507.00
7-Dits
1-Dits
−
72
511.25
513.00
7-Dits
2-Dits
−
73
517.25
519.00
7-Dits
3-Dits
−
