DSIM-CC & DSIM-CF
Setup Guide Rev E
4. DSIM Controller Operation Instruction Guidelines
Switch
Function
Description
+
Increase
In MGC Mode, Click to increase RF output level
In AGC Mode, no function
In TGC Mode, no function
-
Decrease
In MGC Mode, Click to decrease RF output level
In AGC Mode, no function
In TGC Mode, no function
Mode
Mode Change
In MGC mode, Click to go to Align Mode to load
controller channel setting, DSIM module will then
automatically switch to AGC mode
In AGC Mode, Click to return to TGC Mode
In TGC Mode, Click to go to MGC Mode
