DSIM-CC & DSIM-CF
Setup Guide Rev E
5. DSIM Controller Status LED Essentials
6. DSIM Module Status LED Essentials
Operation Blinking Patterns for DSIM Module
LED Blinking Pattern
Indications
Steady Repeating Blue Dashes
Manual Mode
Series of Blue Blinks
Pilot Channel Number See tables in section
9 at the end of the guide for blinking sequences
Single Blue Long Dash Between Series
of Blue Blinks
IRC Analog channel is set
2 Blue Long Dashes Between Series
of Blue Blinks
Digital channel is set
3 Blue Long Dashes Between Series
of Blue Blinks
TGC Mode The default cable length setting for
TGC mode is 27 dB of cable in front of the
amplifier
Quick Blue / Orange Blinks
Pilot paste in progressWait
or Pilot channel not found or lost
LED Blinking Pattern
Indications
Quick Blue / Red Blinks
DSIM controller to module syncing process -
Occurs when controller is installed into the DSIM
module.
Aligning process: in progress
Steady on Blue
In MGC Mode
Series of Blue Blinks
In AGC Mode
Steady on Purple
In TGC Mode
