DSIM-CC & DSIM-CF
Setup Guide Rev E
The DSIM controller is used to set the DSIM modules to the customer selected pilot channel. In
the setup of the DSIM module the pilot channel that is programmed into the controller is
downloaded into the memory of the DSIM module. The pilot channel setting in the DSIM module
can be changed in the future by simply using a controller with the new desired pilot channel
programmed.
3. DSIM Mode Definitions
In the Manual Gain Control (MGC) mode the DSIM automatic gain
control is turned off.
The MGC mode is used during the setup of the station so that no
gain adjustments are made when the levels and slopes are setup.
In Automatic Gain Control (AGC) mode will make gain adjustments
to the station based on the level changes that occur on the pilot
channel.
The DSIM-CC and DSIM-CF do not function in TGC mode. The
only time the TGC function is active is when or if the pilot is lost. If
the pilot is lost the DSIM will compensate based on recent memory
of temperature and bode position.
