ACME LPB-4P - Technical Specification; Control Panel

 LPB-4P
 4B
2. Technical Specification
y Input Voltage: AC 120~240V~50/60Hz
y Power consumption: 67W
y Light Source: total 212 LED (red:70, green: 71, blue: 71, per panel LP-212)
y Fuse: T 3.15A
y Three channel mode: 4 channels & 13 channels & 16 channels
y Dimension: 1060 x 67 x 88 mm (LPB-4)
218 x 38 x 204 mm (LP-212)
y Weight: 9.2kgs (LPB-4P：1 x LPB-4 + 4 x LP-212)
3. How To Set The Package
3.1 Control Panel
Display
To show the various menus and the selected functions
LED
DMX On DMX input present
MASTER On Master Mode
SLAVE On Slave Mode
SOUND Flashing Sound activation
 LPB-4P
 13B
16 channels mode:
