ACME SUPERNOVA - Page 52

- 51 -
Color 1/2 Reset Error
Gobo 1/2 Reset Error
Check whether the position of the gobo wheel 1/2 where the magnet
is installed falls off or is damaged.
Check whether there are obstacles in the gobo wheel 1/2 operating
range.
Check whether the Hall element on the gobo wheel 1/2 is damaged.
Check whether the lead connecting the Hall element on the gobo
wheel 1/2 and the PCB board is in poor contact or disconnected.
Check whether the motor on the gobo wheel 1/2 is damaged.
Check whether the related circuit of the motor drive board on the
gobo wheel 1/2 is damage.
Check whether the position of the color wheel 1/2 where the magnet
is installed falls off or is damaged.
Check whether there are obstacles in the color wheel 1/2 operating
range.
Check whether the Hall element on the color wheel 1/2 is damaged.
Check whether the lead connecting the Hall element on the color
wheel 1/2 and the PCB board is in poor contact or disconnected.
Check whether the motor on the color wheel 1/2 is damaged.
Check whether the related circuit of the motor drive board on the
color wheel 1/2 is damage.
