6.24
OTHER FEATURES
Looseness indicator
The system has a function for detecting
coupling backlash and looseness in order to
achieve optimum accuracy. The system will
display the looseness indicator if one of the
following conditions is met:
• The M and S units are more than 3°
apart.
• The mutual angular position changes
more than 0.7° from that when the first
measurement point was taken.
When the coupling backlash or looseness is
eliminated to avoid any of the above
conditions, the looseness indicator will
automatically disappear.
Target Value symbol
When Target Values are used
in the measurement, this is
indicated with the Target Value
symbol in the upper right corner
of the screen.
