ACORN 80 Maintenance & Service Manual
SECTION 6
Testing & Setting
6.3.15 Amending The Program
6.3.16 Programming The Hinge Zone
The hinge zone is the section of rail from the bottom of the hinge to just above the point on the rail when the
hinge is in the folded position. When this point is reached while programming the rail, switch HINGE ZONE to ON.
Leave this switched on for the remaining program. The lift cannot travel in this section of rail if the hinge interlock
signal is not received from the hinge control box.
6.3.17 Programming Do’s & Don’ts
DO
1 Set the final limit striker in the correct position
2 Only program to the measurements stated in the manual
3 Only program in the down direction
4 Always program creep speed at both terminal stops
5 Ensure confirmation of reset indication on display
6 Do reprogram the final limit if you have reprogrammed within 150mm of the terminal limit
7 Do reprogram full rail system after adjusting potentiometer
DO NOT
1 Do not move the top charge point after datum has been set
2 Do not alter the level calibration potentiometer before or after programming
3 Do not alter the level calibration potentiometer without programming the full system
IF ANY REPROGRAMMING IS REQUIRED WITHIN 150MM OF EITHER THE TOP OR BOTTOM
LIMITS, THE FINAL LIMIT MUST BE REPROGRAMMED AS WELL.
The carriage can be stopped at any time during programming, and if a mistake is made the program can be
over written.
PROGRAM MODE DISABLES THIS SAFETY FEATURE.
