ACORN 80 Maintenance & Service Manual
SECTION 7
Dismantling Components
LEVELLING BOGIE FRONT GENERAL ASSEMBLY
1 Pivot Spindle
2 Centre Block
3 Front Guide Rail Assembly
4 Rear Guide Rail Assembly
5 Slide Assembly – see detailed view
6 Levelling Motor
7 Motor Pulley
8 Ball Screw Pulley
9 Timing belt
10 Ball Screw Assembly
11 Overtravel Limit Switches
THESE ITEMS ARE SHOWN AS PART OF THE ASSEMBLY AND ARE NOT NECESSARILY
COMPLETE SPARE PARTS.
7.8.5 Main Components
