Written by: R Patel Checked by: AJC
Document No.: CBAPP Rev.: 7 Page 10 of 11 Date: 06/06/2003
Manufacturer Part no. Description Maximum
Quantity
Per Zone
Ziton Z630-1 Optical detector 32 *
Ziton Z610-1 Ionisation detector 32 *
Ziton Z6BS2A Mounting base 32 *
KAC KR9-680 Manual call point Unlimited
6.1 Notes
1. When using Hochiki smoke detectors (types SIHE and SLKE) fit a 3K9 0.25 watt resistor
across terminals L1 and S4.
2. When using Nittan detectors with RB3R bases fit a 220 ohm resistor across L and S1.
3. All call points must have a resistor in the range 470 Ohm to 680 Ohm fitted to them.
6.2 Other Compatible Zone Devices Order Codes & Descriptions
Part No Description
2501/012
Break glass unit without back box c/w 680 ohm resistor
2501/013
Break glass unit with back box c/w 680 ohm resistor
2500/226
Remote square indicator
2500/227
Remote round indicator
2501/014
Spare glasses for break glass units (pack of 5)
6.3 General Accessories Order Codes & Descriptions
Part No Description
2501/032
2.1AH S.L.A. battery set (2 x 12V)
2501/040
150mm bell (24 volts DC)
2501/044
Roshni Electronic Sounder (24 volts DC)
2501/043
Xenon flashing beacon (24 volts DC - 2 watts)
2501/033
Door retainer (24 volts DC) - auxiliary power supply required
2501/034
Door retainer (230 volts AC)
2501/035
Door retainer floor bracket
2500/198
1A 24V DC door retainer power supply unit in enclosure (no battery back-up)
Size - 300h x 350w x 75d
2500/197
MPC1 1A power supply unit in enclosure with space for 3.2AH battery set
Size 300h x 350w x 75d
2500/199
MPC3 3A PSU in enclosure with space for 12AH battery set
Size 355h x 370w x 90d
2500/200
MPC5 5A PSU in enclosure with space for 24AH battery set
Size 300h x 360w x 190d
2500/201
MPC10 10A PSU in enclosure with space for 24AH battery set
Size 500h x 500w x 210d
7. Additional Available Documentation
Sales Literature
Installation & Commissioning Manual
User Instructions
Wiring Recommendations
