Acorn CB200 - Technical Specifications

Written by: R Patel Checked by: AJC
Document No.: CBAPP Rev.: 7 Page 6 of 11 Date: 06/06/2003
4. Technical Specifications
CB200 1-2 zone control panel
Maximum field equipment load: 800mA
Auxiliary 24VDC output 250mA
Mains failed current consumption: 35mA
Integral charger output: 500mA
Common fire output:
Common fault output:
Volt- free contacts - 1A, 30V DC max.
Volt- free contacts - 1A, 30V DC max.
Alarm circuit output: 2 at 250mA each
Battery size: 2 x 12V 2.1AH sealed lead acid
Weight (excluding batteries): 2.3kg
CB200 4 zone control panel
Maximum field equipment load: 800mA
Auxiliary 24VDC output 250mA
Mains failed current consumption: 40mA
Integral charger output: 500mA
Common fire relay:
Common fault output:
Volt- free contacts - 1A, 30V DC max.
Volt- free contacts - 1A, 30V DC max.
Alarm circuit output: 4 at 500mA each
Battery size: 2 x 12V 2.1AH sealed lead acid
Weight (excluding batteries): 2.3kg
CB200 8 zone control panel
Maximum field equipment load: 800mA
Auxiliary 24VDC output 250mA
Mains failed current consumption: 40mA
Integral charger output: 500mA
Common fire relay:
Common fault output:
Volt- free contacts - 1A, 30V DC max.
Volt- free contacts - 1A, 30V DC max.
Alarm circuit output: 4 at 500mA each
Battery size: 2 x 12V 2.1AH sealed lead acid
Weight (excluding batteries): 2.4kg
CB200 8 zone repeater panel with power supply
Mains failed current consumption: 40mA @24VDC
Integral battery charger output: 500mA @27.5VDC
Auxiliary 24VDC output 250mA
Battery size: 2 x 12V 2.1AH sealed lead acid
Weight (excluding batteries): 2.4kg
CB200 8 zone control panel powered from panel
Current consumption: 40mA @24VDC
Weight: 1.4kg
