SYNCHRONY EQUIPMENT USER MANUAL 27
© COPYRIGHT 2015-2021, ACCELERATED CARE PLUS CORP., ALL RIGHTS RESERVED
CONFIDENTIAL AND PROPRIETARY
TECHNICAL SPECIFICATIONS
OMNIsEMG
™
Transmitter / Sensor
Geometry Variable
Electrodes Standard sensing electrode with clip connection
Battery Rechargeable lithium ion
Dimensions 17mm x 36mm x 8mm
Weight
<9g battery included
Frequency ISM band 2.4GHz (standard IEEE802.15.4)
Input Impedance
>10G Ohms
CMMR
>110db @ 50–60Hz
Resolution 16bit
Acquisition frequency Up to 4KHz
Sensitivity
1µV
OMNIsEMG
™
Receiver / Dongle
Dimensions 152mm x 82mm x 22mm
Weight 240g
OMNIsEMG
™
Ambient conditions for operation
-20 ºC to +45 ºC
50 to 80% Rh, non-condensing
Ambient conditions for storage or transportation
0 ºC to +40 ºC
50 to 80% Rh, non-condensing
Altitude 0 to 2000M
Autonomy Up to 24 hours with rechargeable battery
ACP reserves the right to change technical specifications and product availability without notice.
