Y1-03-0138R 7
Figure 2 - Point Pad™ Connection Block Diagram
URP-102
Point Pad
URP-102
Point Pad
URP-102
Point Pad
URC-102
Master
Controller Unit
URC-102
Master
Controller Unit
Power
Source
Power
Source
RG-59 Coaxial Cable
Fuse
Fuse
“T” Conn.
or Splitter
Single Point Pad
Multiple Point Pads
