Output delay time
In case of DO output mode, set as 0, potential control mode; set as non 0 pulse control
mode, disconnection after delay set time, unit: 1 second;
Scope of high alarm value -9999～9999 (decimal point not considered)
Scope of low alarm value -9999～9999 (decimal point not considered)
Lo.on signal 0, low alarm may be triggered
Lo.oF signal 0, low alarm is not triggered
Note: 1. Indication of three phase XX maximum/minimum value: high alarm represents maximum value of
three phase; low alarm represents minimum value of three phase.
2.Second way DO to be set as "32.FL" combination alarm function; after setting, level II menu
changed as "SEL" (function selection), "dLy" (delay), "H-U" (high voltage), "L-U" (low voltage), "H-F" (high
frequency), "L-F" (low frequency), "H-P" (high frequency), "L-P" (low frequency), "H-I" (high current), "L-PF"
(low power factor), " H-b.U" (over voltage unbalance, set as -1 phase miss, judgement condition at least
one phase>0.5Ue, at least one phase<0.1Ue), " H-b.I" (over current unbalance, set as -1 phase
miss,judgement condition at least one phase>0.2Ie,, at least one phase<0.01Ie).
(Difference between maximum deviation from the mean value and mean value)/mean value *100%, if the
mean value of denominator is less than the rated value, the denominator is rated value; voltage rated value
Ue; 3 phase 4 wire Ue as the phase voltage, menu setting 400V instrument as 220V*PT, 100V instrument
as 57V*PT. Current rated value Ie: 5A instrument as 5A*CT, 1A instrument as 1A*CT.
Unbalance set parameter in percentage, e.g. 20 means 20%
6.2.6.5Transmission setting
（
Function not available for the time being
）
6.2.6.6Event setting
