Acrel ACR10R-D24TE4 User Manual

`
- 2 -
Note:the instrument must be installed on site with the supporting open and closed transformer
or roche coil.
1. General
The guide-rail harmonic meter with external roche coil and open type mutual inductor is suitable
for energy saving renovation projects in high energy consumption industries such as
smelting,steel,electric welding,semiconductor,etc.And also for power monitoring of distributed
photovoltaic grid-connected cabinet,power demand side management and other applications.The
utility model has the advantages of no need to remove primary bus,simple and convenient wiring,safe
construction,saving transformation cost and improving efficiency for users.It integrates the
measurement of all power parameters(such as current,voltage,active power,reactive power,apparent
power,frequency,power factor,etc.),multi-rate electric energy measurement,four-quadrant
electric energy measurement,harmonic analysis and electric energy monitoring and assessment
management.At the same time, it has a variety of peripheral interface for user to choose:with
RS485 communication interface,modbus-rtu protocol can meet the needs of communication network
management;The function of “remote signal” and “remote control” of circuit breaker switch
can be realized with switch quantity input and relay output.LCD display interface is adoped to
realize parameter setting and control through panel keys,which is very suitable for real-time
power monitoring system.
2．Size of product
ACR 10R H - / -
Open type transformer model： D10-Φ 10mm， 80A; D16-Φ 16mm， 120A
D24-Φ 24mm ， 200A; D36-Φ 36mm， 300A
Roche coil model： D110-Φ 110mm， 1000A; D120-Φ 120mm， 2000A
D140-Φ 140mm ， 6300A; D190-Φ 190mm， 20000A
T-External opening transforme R-External Roche coil
ACR series netxork power instrument
10R-Guide rail installation
J-Relay alarm output over limit K-Switch input/output(I/O module)
D-Maximum demand F-Multiple rate electric energy
SOE-Incident record
H-Harmonic measurement
E3-three-phase,three-wire E4-three-phase,four-wire
No-AC/DC 85-270V P1-DC24V,48V
3．Product function
model
Functional characteristic
ACR10RH-DxxT(R)E4
ACR10RH-DxxT(R)E3
Display mode
LCD（Field LCD）
■
Measuring
parameter
Current/voltage/frequen
cy/power facto
■
