6.2.3 Electric energy display interface
1 、 Four-quadrant electric energy refers to forward active power,reverse active power,inductive reactive
power and capacitive reactive power respectively.Generally speaking,users read forward active power
EPI;The energy measurement of the double rate is divided into two time zones,one time zone is 8
times,and the second time zone is 9 times(one time zone can be set by buttons and communication).The
second time zone can only be set in the middle,if the factory has been set to a double time zone,the
adjustment menu setting rate can onlymodify the contents of a time zone,to be modified to a single time
area,communication settings),four rates (F0-active poined peak power,F1-active peak power,F2-active flat
electric energy,F3-active valley electric energy)to complete the time-sharing measurement of electric
energy.
2、T represents the total compound rate of active electricity for the month.
3、When jumping from 23:59:59 to 00:00:00 on the 1
st
of the following month,the EPI value of monthly
active power will automatically be put into the dis interface of “active Power EPI(F0-T) last month”.Last
month,the active power EPI(F0-T) value was put into the display interface of “active power EPI(F0-T) the
month before last”,and the display value of “active power EIMP (F0-F4)of this month”was zero
6.2.4 Switch status display interface
6.2.5 Incident record
Four quadrant electric energy
Last monthundefineds compound
rate of active electricity
The month before last compound rate
of active electricity
Total compound rate active
electricity
To Next Page
