Acrel ACR10R-D24TE4 User Manual

`
- 42 -
power
26
Phase B reactive
power
68 99 99 99 99 99 99 68 01 02 75 E9 C7 16
2
XX．XX
kvar
27
Phase C reactive
power
68 99 99 99 99 99 99 68 01 02 76 E9 C8 16
2
XX．XX
kvar
28
Conjuction power
factor
68 99 99 99 99 99 99 68 01 02 83 E9 D5 16
2
X．XXX
29
Phase A power
factor
68 99 99 99 99 99 99 68 01 02 84 E9 D6 16
2
X．XXX
30
Phase B power
factor
68 99 99 99 99 99 99 68 01 02 85 E9 D7 16
2
X．XXX
31
Phase C power
factor
68 99 99 99 99 99 99 68 01 02 86 E9 D8 16
2
X．XXX
32
Reading date
68 99 99 99 99 99 99 68 01 02 43 F3 9F 16
4
YYMMDDWW
WW=00
33
Reading time
68 99 99 99 99 99 99 68 01 02 44 F3 A0 16
3
hhmmss
34
Switch state value
68 99 99 99 99 99 99 68 01 02 56 F3 B2 16
1
See
attachment
1
35
Voltage rate
68 99 99 99 99 99 99 68 01 02 68 F3 C4 16
2
XXXX
36
Current rate
68 99 99 99 99 99 99 68 01 02 69 F3 C5 16
2
XXXX
37
Switch output
68 99 99 99 99 99 99 68 04 03 56 F3 00 B6 16
0
The total
switch
volume
output has
4 ways:：
DO1-D04
38
Set DO1
68 99 99 99 99 99 99 68 04 03 56 F3 01 B7 16
0
39
Set DO2
68 99 99 99 99 99 99 68 04 03 56 F3 02 B8 16
0
40
Set DO1, DO2
68 99 99 99 99 99 99 68 04 03 56 F3 03 B9 16
0
Attachment 1：
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
DI1
DI2
DI3
DI4
DO1
DO2
DO3
DO4
