Acrel ACR10R Series User Manual

`
- 21 -
133
Second
R/W
1
143-148
Event record 1
RO
retain
6
149-154
Event record 2
RO
retain
6
155-160
Event record 3
RO
retain
6
161-166
Event record 4
RO
retain
6
167-172
Event record 5
RO
retain
6
173-178
Event record 6
RO
retain
6
179-184
Event record 7
RO
retain
6
185-190
Event record 8
RO
retain
6
191-196
Event record 9
RO
retain
6
197-202
Event record 10
RO
retain
6
203-208
Event record 11
RO
retain
6
209-214
Event record 12
RO
retain
6
215-220
Event record 13
RO
retain
6
221-226
Event record 14
RO
retain
6
227-232
Event record 15
RO
retain
6
233-238
Event record 16
RO
retain
6
242
Neutral current
RO
Secondary side Current decimal
Point digital:3
1
243
Phase Voltage Uan
RO
Secondary side Voltage decimal
Point digital:1
1
244
Phase Voltage Ubn
RO
Secondary side
1
245
Phase Voltage Ucn
RO
Secondary side
1
246
Line Voltage Uab
RO
Secondary side
1
247
Line Voltage Ubc
RO
Secondary side
1
248
Line Voltage Uca
RO
Secondary side
1
249
Phase Current Ia
RO
Secondary side Current decimal
Point digital:3
1
250
Phase Current Ib
RO
Secondary side
1
251
Phase Current Ic
RO
Secondary side
1
252
Frequency F
RO
Frequency decimal
Point digital:2
1
253-254
Phase A Active power Pa
RO
Secondary side power decimal，Point
digital:2，unit:W
2
255-256
Phase B Active power Pb
RO
Secondary side power decimal ， Point
digital:2，unit:W
2

Acrel ACR10R Series Specifications

General

Model	ACR10R series
Communication	RS485, Modbus-RTU
Protection	IP20
Display	LCD
Power Supply	AC/DC
Rated Current	AC 1A, AC 5A
Frequency	45Hz - 65Hz
Accuracy class	0.5
Power consumption	<5VA
Operating temperature	+55°C
Storage temperature	-25℃~+70℃
Safety	IEC/EN 61010-1
EMC	IEC 61326-1
Relative Humidity	≤95% (non-condensing)
Voltage overload	1.2x rated voltage continuously, 2x rated voltage for 1 second
