Acrel ACR10R Series User Manual

`
- 22 -
257-258
Phase C Active power Pc
RO
Secondary side power decimal ， Point
digital:2，unit:W
2
259-260
Total.Active power PTotal
RO
Secondary side power decimal ， Point
digital:2，unit:W
2
261-262
Phase A Reactive power Qa
RO
Secondary side power decimal ， Point
digital:2，unit:var
2
263-264
Phase B Reactive power Qb
RO
Secondary side power decimal ， Point
digital:2，unit:var
2
265-266
Phase C Reactive power Qc
RO
Secondary side power decimal ， Point
digital:2，unit:var
2
267-268
TotalReactive power QTotal
RO
Secondary side power decimal ， Point
digital:2，unit:var
2
269-270
Phase A Apparent powerSa
RO
Secondary side power decimal ， Point
digital:2，unit:VA
2
271-272
Phase B Apparent powerSb
RO
Secondary side power decimal ， Point
digital:2，unit:VA
2
273-274
Phase C Apparent powerSc
RO
Secondary side power decimal ， Point
digital:2，unit:VA
2
275-276
TotalApparent power STotal
RO
Secondary side power decimal ， Point
digital:2，unit:VA
2
277
Phase A power factor
RO
power factordecimal Point digital:3
1
278
Phase B power factor
RO
1
279
Phase C power factor
RO
1
280
Total power factor
RO
1
287
Phase A Current K factor
RO
K factor decimal Point digital:2
1
288
Phase B Current K factor
RO
1
289
Phase C Current K factor
RO
1
299
Unbalance factor of voltage
RO
Unbalance factor of voltage
decimal Point digital:1
1
300
Unbalance factor of current
RO
Unbalance factor of current
decimal Point digital:1
1
301-302
Maximum demand
RO
Maximum demand decimal Point digital:2
2
303-306
Maximum demand occurrence
time
RO
Time;// BCD code format
4
333-334
This month active Peak
Electric energy
RO
Secondary side Electric energy
2-bit decimal Point，unit:kWh
2

Acrel ACR10R Series Specifications

General

Model	ACR10R series
Communication	RS485, Modbus-RTU
Protection	IP20
Display	LCD
Power Supply	AC/DC
Rated Current	AC 1A, AC 5A
Frequency	45Hz - 65Hz
Accuracy class	0.5
Power consumption	<5VA
Operating temperature	+55°C
Storage temperature	-25℃~+70℃
Safety	IEC/EN 61010-1
EMC	IEC 61326-1
Relative Humidity	≤95% (non-condensing)
Voltage overload	1.2x rated voltage continuously, 2x rated voltage for 1 second
