Page #26 background image
`
- 23 -
335-336
This month active Flat Electric
energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
337-338
This month active Valley
Electric energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
339-340
This month active Total Electric
energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
341-342
Last month active Peak
Electric energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
343-344
Last month active Flat Electric
energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
345-346
Last month active Valley
Electric energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
347-348
Last month active Total Electric
energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
349-350
Month before last active Peak
Electric energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
351-352
Month before last active Flat
Electric energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
353-354
Month before last active Valley
Electric energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
355-356
Month before last active Total
Electric energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
357-358
Total active Peak Electric
energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
359-360
Total active Flat Electric energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
361-362
Total active Valley Electric
energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
363-364
Total multi-rate active Electric
energy
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
365-366
Forward active Electric energy
EPI
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
367-368
Backward active Electric
energy EPE
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2
369-370
Forward reactive Electric
energy EQI
RO
Secondary side Electric energy
2-bit decimal Pointunit:kWh
2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Acrel ACR10R Series and is the answer not in the manual?

Acrel ACR10R Series Specifications

General IconGeneral
ModelACR10R series
CommunicationRS485, Modbus-RTU
ProtectionIP20
DisplayLCD
Power SupplyAC/DC
Rated CurrentAC 1A, AC 5A
Frequency45Hz - 65Hz
Accuracy class0.5
Power consumption<5VA
Operating temperature+55°C
Storage temperature-25℃~+70℃
SafetyIEC/EN 61010-1
EMCIEC 61326-1
Relative Humidity≤95% (non-condensing)
Voltage overload1.2x rated voltage continuously, 2x rated voltage for 1 second
