Acrel ACR10R Series User Manual

`
- 24 -
371-372
Backward reactive Electric
energy EQC
RO
Secondary side Electric energy
2-bit decimal Point，unit:kWh
2
373-402
A Phase Voltage 2-31 order
harmonic ratio
RO
A Phase Voltage 2-31 order harmonic;2-bit
decimal point
30
403-432
B Phase Voltage 2-31 order
harmonic ratio
RO
A Phase Voltage 2-31 order harmonic;2-bit
decimal point
30
433-462
C Phase Voltage 2-31 order
harmonic ratio
RO
C Phase Voltage 2-31 order harmonic ,2-bit
decimal point
30
463-492
A Phase Current 2-31 order
harmonic ratio
RO
A Phase Current 2-31 order harmonic,2-bit
decimal point
30
493-522
B Phase Current 2-31 order
harmonic ratio
RO
B Phase Current 2-31 order harmonic,2-bit
decimal point
30
523-552
C Phase Current 2-31 order
harmonic ratio
RO
C Phase Current 2-31 order harmonic,2-bit
decimal point
30
553
A Phase Voltage Total
harmonic distortion
RO
A Phase Voltage Total harmonic
content;decimal point digital:2
1
554
B Phase Voltage Total
harmonic distortion
RO
B Phase Voltage Total harmonic
content;decimal point digital:2
1
555
C Phase Voltage Total
harmonic distortion
RO
C Phase Voltage Total harmonic
content;decimal point digital:2
1
556
A Phase Current Total
harmonic distortion
RO
A Phase Current Total harmonic
content;decimal point digital:2
1
557
B Phase Current Total
harmonic distortion
RO
B Phase Current Total harmonic
content;decimal point digital:2
1
558
C Phase Current Total
harmonic distortion
RO
C Phase Current Total harmonic
content;decimal point digital:2
1
559-590
A Phase Voltage sampling
point(32 point/wave)
RO
A Phase Voltage sampling point
32
591-622
B Phase Voltage sampling
point(32 point/wave)
RO
B Phase Voltage sampling point
32
623-654
C Phase Voltage sampling
point(32 point/wave)
RO
C Phase Voltage sampling point
32
655-686
A Phase Current sampling
point(32 point/wave)
RO
A Phase Current sampling point
32
687-718
B Phase Current sampling
point(32 point/wave)
RO
B Phase Current sampling point
32

Acrel ACR10R Series Specifications

General

Model	ACR10R series
Communication	RS485, Modbus-RTU
Protection	IP20
Display	LCD
Power Supply	AC/DC
Rated Current	AC 1A, AC 5A
Frequency	45Hz - 65Hz
Accuracy class	0.5
Power consumption	<5VA
Operating temperature	+55°C
Storage temperature	-25℃~+70℃
Safety	IEC/EN 61010-1
EMC	IEC 61326-1
Relative Humidity	≤95% (non-condensing)
Voltage overload	1.2x rated voltage continuously, 2x rated voltage for 1 second
