Page #28 background imageLoading...
Page #28 background image
`
- 25 -
719-750
C Phase Current sampling
point(32 point/wave)
RO
C Phase Current sampling point
32
1000
DIDO state
R/W
High bytes DI (bit 0 as DI1, bit 1 as DI2, like
this, bit 7 as DI8), low bytes DO (bit 0 as
DO1, bit 1 as DO2, like this, bit 7 as DO8)
1
1001
First way alarm selection
R/W
0-32, details given in correlation in table
7.1.5, e.g. total active power alarm, value 16
1
1002
First way alarm delay
R/W
0–9999 unit: s; e.g. total active power alarm,
the value being 16
1
1003
First way alarm dead zone
R/W
-9999 9999 details given in 7.1.5, e.g.
reading 66.00Kw, communication value
6600
1
1004
First way high alarm
R/W
1
1005
First way low alarm
R/W
1
1006
First way 0 alarm
R/W
0 1 (0: enabled, 1: disabled)
1
1007-1012
Second way (same as above)
R/W
One more combination alarm selection than
the first way, type selection 0-33 (in case of
value 33, corresponding set address
1030-1037 effective), the remaining same as
first way
6
1013-1018
Third way (same as above)
R/W
Same as first way
6
1019-1024
Fourth way (same as above)
R/W
Same as above
6
1030
Over frequency
R/W
-9999 9999 only effective when the second
way alarm is the combination alarm, details
given in 7.1.5; e.g. reading 66.00Kw,
communication value 6600
1
1031
Under frequency
R/W
1
1032
Over power
R/W
1
1033
Under power
R/W
1
1034
Over current
R/W
1
1035
Under power factor
R/W
1
1036
Over voltage unbalance
R/W
-1 9999 details given in 7.1.5, e.g.: reading
55.00Kw, communication value 5500
1
1037
Over current unbalance
R/W
1
1038
Combination alarm state
RO
0 bit indicates over voltage alarm state, first
bit indicates under voltage alarm state, in the
same manner till bit 9
1
1040
First way transmission
selection (low bytes effective)
R/W
1
1041
First way high transmission
R/W
1
1042
First way low transmission
R/W
1
