Acrel ACR10R Series User Manual

`
- 28 -
2124-2185
Phase C voltage 2-63
harmonic content
RO
Phase C voltage 2-63 harmonic; decimal
points: 2
62
2186-2247
Phase A current 2-63 harmonic
content
RO
Phase A current 2-63 harmonic; decimal
points: 2
62
2248-2309
Phase B current 2-63 harmonic
content
RO
Phase B current 2-63 harmonic; decimal
points: 2
62
2310-2371
Phase C current 2-63 harmonic
content
RO
Phase C current 2-63 harmonic; decimal
points: 2
62
2372
Phase A voltage total harmonic
distortion
RO
Phase A voltage total harmonic content;
decimal points: 2
1
2373
Phase B voltage total harmonic
distortion
RO
Phase B voltage total harmonic content;
decimal points: 2
1
2374
Phase C voltage total harmonic
distortion
RO
Phase C voltage total harmonic content;
decimal points: 2
1
2375
Phase A current total harmonic
distortion
RO
Phase A current total harmonic content;
decimal points: 2
1
2376
Phase B current total harmonic
distortion
RO
Phase B current total harmonic content;
decimal points: 2
1
2377
Phase C current total harmonic
distortion
RO
Phase C current total harmonic content;
decimal points: 2
1
3000 High
byte
Decimal point U (DPT)
RO
3-7
0.5
3000 Low
byte
Decimal point I (DCT)
RO
1-5
0.5
3001 High
byte
Decimal point PQ(DPQ)
RO
4-10
0.5
3001 Low
byte
Symbol PQ
RO
high bit-low bit：Q、Qc、Qb、Qa、P、Pc、Pb、
Pa
0 is positive, 1 is negative
0.5
3002
Phase voltage average
RO
primary side
1
3003
Line voltage average
RO
primary side
1
3004
Current average
RO
primary side
1
3008-3009
System uptime
R/W
In seconds, the high byte before, and the low
byte in the back.
2
3010
phase voltage Uanmaximum
RO
primary side
1

Acrel ACR10R Series Specifications

General

Model	ACR10R series
Communication	RS485, Modbus-RTU
Protection	IP20
Display	LCD
Power Supply	AC/DC
Rated Current	AC 1A, AC 5A
Frequency	45Hz - 65Hz
Accuracy class	0.5
Power consumption	<5VA
Operating temperature	+55°C
Storage temperature	-25℃~+70℃
Safety	IEC/EN 61010-1
EMC	IEC 61326-1
Relative Humidity	≤95% (non-condensing)
Voltage overload	1.2x rated voltage continuously, 2x rated voltage for 1 second
