5.4.2 How to modify the analog output settings(Only AMC96 instrument supports analog output function)
For example: set the line voltage Uab to correspond to the first analog 0-20mA output at 19-381V，The
settings are shown in Figure 25.
Figure 25
Table 7
First channel analog output
Analog output item selection
When the analog output is 20mA, the corresponding electrical parameter is taken as the highest
four-digit integer (the decimal point is ignored) and the last bit is zero.
Note: The analog output setting includes the analog output selection, the analog output full scale corresponding
