19
4.Unbalance calculation
(Difference between maximum deviation from the mean value and mean value)/mean value *100%,if the mean
value of denominator is less than the rated value, the denominator is rated value; voltage rated value Ue; 3 phase 4
wire Ue as the phase voltage, menu setting 400V instrument as 220V*PT, 100V instrument as 57V*PT.Current
rated value Ie: 5A instrument as 5A*CT, 1A instrument as 1A*CT.
Unbalance set parameter in percentage, e.g. 20 means 20%.
6 Communication
6.1 Register listing(MODBUS-RTU)
Table 9
Address
Parameter
Read or
write
Value range
Data
type
0000H
Password saved
R/W
0001-9999
Uint16
0001H high
byte
Communication address
R/W
0001-0247
Uint16
0001H low
byte
Communication baud rate
R/W
0-33840019200 96004800bps
0002H
Control character
R/W
8th bit-connection mode
(0-3-phase-4-we, 1-3-phase-3-wire)
7th bit-input voltage range (0-400V, 1-100V)
second bit-input current range (0-5A, 0-1 A)
Uint16
0003H
PT transformation ratio
R/W
1-9999
Uint16
0004H
CT transformation ratio
R/W
1-9999
Uint16
0005H
First analog output
parameter setting
Analog output selection
R/W
The low byte is valid, and the corresponding
parameter refers to the SEL correspondence in
5.4.2.
Uint16
0006H
First analog output
parameter setting
Analog output full scale
corresponding value
R/W
-99999999(Same as analog output setting
menu 5.4.2 in Ao.Hi)
Int16
0007H
First analog output
parameter setting
Analog output zero point
corresponding value
R/W
-99999999(Same as analog output setting
menu 5.4.2 in Ao.Lo)
Int16
0008H-000AH
Second analog output
parameter setting
R/W
Same as the first analog output parameter
setting
Uint16
000BH-000D
H
Third analog output
parameter setting
R/W
Same as the first analog output parameter
setting
Uint16
000EH-0010H
Fourth analog output
parameter setting
R/W
Same as the first analog output parameter
setting
Uint16
0011H high
Backlight control
R/W
Only applied to LCD Display meters 0= lights
Uint16
