Acrel AMC Series User Manual

20
byte
0012H
rt-1 hour，rt-1 minute
R/W
high byte:rt-1 hour，
low byte:
rt-1 minute
Uint16
0013H
rt-1 multiple rate，rt-2 hour
R/W
high byte:rt8-rt1 multiple rate(1 sharp, 2 peak,
3 flat, 4 valley)，
low byte:
rt-2 hour
Uint16
0014H
rt-2 minute，rt-2 multiple
rate
R/W
high byte:rt-2 minute，
low byte:
rt1-rt2 multiple
rate(1 sharp, 2 peak, 3 flat, 4 valley)
Uint16
0015H-0017H
Rt-3, rt4 setting
R/W
Same as rt-1, rt-2 setting
Uint16
0018H-001AH
rt-5，rt6 setting
R/W
Same as rt-1, rt-2 setting
Uint16
001BH-001D
H
rt-7，rt8 setting
R/W
Same as rt-1, rt-2 setting
Uint16
001EH～
0020H
Date time setting
R/W
Year, Month, Day, Hour, Minute, Second
Uint16
0021H high
byte
Automatic meter reading
day
R/W
Month, day
Uint16
0021H low
byte
Current time rate
R/W
1 sharp, 2 peak, 3 flat, 4 valley
0022H
Switching input and
output status
R/W
See 6.2.1
Uint16
0023H high
byte
Decimal point U (DPT)
R
3～7
Uint16
0023H low
byte
Decimal point I (DCT)
R
1～5
0024H high
byte
Decimal point PQ (DPQ)
R
4～10
Uint16
0024H low
byte
Symbol PQ
R
High byte-low byte:Q、Qc、Qb、Qa、P、Pc、
Pb、Pa;
0 is positive and 1 is negative
The following is the primary side power parameter
0025H
UAN
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
0026H
UBN
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
0027H
UCN
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
0028H
UAB
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
0029H
UBC
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
002AH
UCA
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
002BH
IA
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
002CH
IB
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
002DH
IC
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
002EH
PA
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
002FH
PB
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
