Acrel AMC Series User Manual

21
0030H
PC
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
0031H
Psum
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
0032H
QA
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
0033H
QB
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
0034H
QC
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
0035H
Qsum
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
0036H
PFA
R
0-1000 (see 6.2.2 for conversion formula)
Uint16
0037H
PFB
R
0-1000 (see 6.2.2 for conversion formula)
Uint16
0038H
PFC
R
0-1000 (see 6.2.2 for conversion formula)
Uint16
0039H
PFsum
R
0-1000 (see 6.2.2 for conversion formula)
Uint16
003AH
SA
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
003BH
SB
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
003CH
SC
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
003DH
Ssum
R
0-9999 (see 6.2.2 for conversion formula)
Uint16
003EH
F
R
4500-6500(see 6.2.2 for conversion formula)
Uint16
The following is the energy address table
003FH～
0040H
Absorptive active electric
energy secondary side
R
0-999999999(see 6.2.2 for conversion
formula)
Uint32
0041H～
0042H
Release active electric
energy secondary side
R
0-999999999(see 6.2.2 for conversion
formula)
Uint32
0043H～
0044H
Inductive reactive
electric energy secondary
side
R
0-999999999(see 6.2.2 for conversion
formula)
Uint32
0045H～
0046H
Capacitive reactive
electric energy secondary
side
R
0-999999999(see 6.2.2 for conversion
formula)
Uint32
0047H～
0048H
absorptive active electric
energy primary side
R
(see 6.2.2 for conversion formula)
Float
0049H～
004AH
Release active electric
energy primary side
R
(see 6.2.2 for conversion formula)
Float
004BH～
004CH
Inductive reactive
electric energy primary
side
R
(see 6.2.2 for conversion formula)
Float
004DH～
004EH
Capacitive reactive
electric energy primary
side
R
(see 6.2.2 for conversion formula)
Float
The following is the primary side zero sequence voltage and current address table
0074H
Zero sequence voltage
R
0-9999(see 6.2.2 for conversion formula)
Uint16
0075H
Zero sequence current
R
0-9999(see 6.2.2 for conversion formula)
Uint16
0076H
Current percentage
R
Unit 0.01%
Uint16
0077H
Voltage current phase
sequence state
R
高位：电流，低位：电压 0：正常 1：错误
Uint16
0078H-0079H
Running time
R
Unit 1min
Uint32
007AH～
007DH
Data time
R
Year、mouth、day、hour、min、second、
millisecond
Uint16
