13
5.2.7 View the AMC72L/96L event record parameters as shown in Figure 22.
Figure 22
5.2.8 View the extreme value parameters of the AMC72L/96L as shown in Figure 23.
Figure 23
Note: There are no interface voltage maximum value and phase voltage minimum value interface for three-phase
three-wire.
5.3 Programming menu
5.3.1 Meter general programming menu
Table 5
First menu
Second menu
Tertiary menu
Description
Start-up display selection: 0-automatic page
turning; other page numbers correspond to
the current meter model power parameter
interface.
09999
Password setting (Initial password 0001)
Press ENTER key Electric energy clear
Press Enter key, clear demand record
Press Enter key, clear demand record
E1/E2
Primary(EI) or secondary(E2) energy
display option,The default is E1.
1.6-160.0
Constant of Energy plus(e.g:10.0-
10000imp/kWh)
